Name:	Danfoss Superheat controller, EIM 336, Electron. control accessories 080G1002
Brand:	Danfoss
Model No.:	EIM 336
Part No.:	080G1002
Country of origion:
G.W:	0.05kgs/pc
Enclosure rating IP:	IP00
Spec. Factory settings:	YES

Danfoss Superheat controller, EIM 336, Electron. control accessories 080G1002

Product details

Ambient temperature range [°C] [max]	60 °C
Ambient temperature range [°C] [min]	-25 °C
Analog inputs (AI) [pc]	3 pc
Analog outputs (AO) [pc]	0 pc
Approval	CE EAC LLC CDC EURO-TYSK RoHS
CE evaluated	Yes
China RoHS compliance	Out of scope
Communication type	Modbus RS485 RTU
Contain batteries	No
Digital inputs (DI) [pc]	1 pc
Display - option	None
Display on front	No
Division	01
EEE category	5 small equipment (any external dimension < 50 cm)
Enclosure rating IP	IP00
EU RoHS compliance	Yes
EU RoHS exemption clause	No
Frequency [Hz]	50/60 Hz
In scope of WEEE	Yes
Max. current output/phase [A]	1 A

Mounting method	Screw mounting
Number of pressure sensors	1
Number of temperature sensors	2
Other RoHS documentation	EAEU RoHS
Packing format	Multi pack
PFAS content [Yes/No]	No
Pressure sensor support	Ratiometric 0.5 - 4 V DC
Product accessories	Electron. control accessories
Product features	Alarm management Superheat reference
Product Language	English
Quantity per packing format	40 pc
REACH Candidate List substances	No
Serviceable	No
Spec. Factory settings	YES
Supply voltage [V] AC	24 V
Supply voltage [V] DC	24 V
Temp. sensor configuration	S2
Temp. sensor support	Pt 1000
Valve output number	1
Valve output type	ETS 6
