Name:	Danfoss Pack controller, AK-PC 551 080G0281
Brand:	Danfoss
Model No.:	AK-PC 551
Part No.:	080G0281
Country of origion:	Romania
G.W:	0.662kgs/pc
Function:	2 Suction and common Condenser
Digital inputs (DI) [pc]:	8
Supply voltage [V] AC:	110 - 230
Communication type:	MODBUS
Packing format:	Multi pack
Quantity per packing format:	12

Danfoss Pack controller, AK-PC 551 080G0281

Product details

Type	AK-PC 551
Product group	Compressor/condenser control
Product Name Description	Pack controller

1 Primary battery SUM weight Kg	0.001
1 Primary battery weight Kg	0.001
Analog inputs (AI) [pc]	8 pc
Analog outputs (AO) [pc]	2 pc
Application area	Capacity control
Approval	CE CMIM EAC cURus
Battery qty	1
Battery type or Name	Lithium coin cell (CR1620)
Capacity control input	Pressure/ Temperature
Capacity control mode	PI
CE evaluated	Yes
China RoHS compliance	Out of scope
Communication type	MODBUS
Compressor capacity mode	Step/ Speed/ PWM
Condenser control type	Pressure/ Temperature
Contain batteries	Yes
Digital inputs (DI) [pc]	8 pc
Digital outputs (DO) [pc]	8 pc
Display - option	On front. Option: MMIGRS2
Display on front	Yes
Division	25
Equipment	Incl. Connectors

EU RoHS compliance	Out of scope
Fan capacity control	Step/ Speed
Fan control mode	PI
Frequency [Hz]	50/60 Hz
Function	2 Suction and common Condenser
Further information	Relays 5,6 solid state type
Mounting method	DIN rail
Number of Compressors max.	8 pc
Other RoHS documentation	EAEU RoHS
Packing format	Multi pack
PFAS content [Yes/No]	No
Power consumption [W]	10 W
Product accessories	Electron. control accessories
Product features	Buzzer Compressor safety Discharge gas temp. safety Fan safety Floating condenser pressure Heat recovery function High pressure safety LCD display built in Load shedding Low pressure safety Night optimization P0 optimization Real time clock Suction gas temp. safety
Product Language	Croatian Czech Danish Dutch English French German Hungarian Italian Polish Portuguese Romania Russian Serbian Spanish Turkish
Quantity per packing format	12 pc
REACH Candidate List substances	No
Serviceable	No
Supply voltage [V] AC [max]	230 V
Supply voltage [V] AC [min]	110 V
Type designation	AK-PC 551
UL evaluated	Yes
