Name:	Danfoss Hand operated regulating valve, REG-SB 20,148B5303
Brand:	Danfoss
Model No.:	REG-SB 20
Part No.:	148B5303
Country of origin:	China
G.W:	1.926kgs/pc
Outlet connection size [mm]:	20
Inlet connection size [mm]:	20
Inlet connection type:	Butt weld
Outlet connection type:	Butt weld
Kv value [m³/h]:	5
Max. Working Pressure [bar]:	52

Danfoss Hand operated regulating valve, REG-SB 20,148B5303

Product details

Type	REG-SB 20
Product group	Shut-off and regulating valves
Product Name Description	Hand operated regulating valve

Kv value [m³/h]	5 m³/h
Max. Working Pressure [bar]	52 bar
Max. Working Pressure [psig]	754 psig
Neck	Standard
Outlet connection size [in]	3/4 in
Outlet connection size [mm]	20 mm
Outlet connection type	Butt weld
Packing format	Single pack
Parts Program name	REG-SA / REG-SB
PED category	Art. 3, par. 3
Product accessories	SVL Flexline accessories
Product description	Hand Regulating Valve
Quantity per packing format	1 pc
REACH Candidate List substances	No
Refrigerants	R134a R22 R290 R401A R402A R404A R407A R407B Read more
Serviceable	SVL Flexline spare parts
Temperature range [°C] [max]	150 °C
Temperature range [°C] [min]	-60 °C
Temperature range [°F] [max]	302 °F
Temperature range [°F] [min]	-76 °F
Valve version	Standard version
