Copeland DWM Semi Hermetic Compressor LSGP-40X-EWL

Copeland

The Copeland standard K, L and S-series compressors have a range from 0.5 to 70hp for use with R404A, R507, R407C, R134a and R22 refrigerants, offering broad application flexibility. Compressors are charged with Polyolester oil and are supplied with an internal oil pump, shut off valves and mounting kits along with non-active capacity control on 4, 6 & 8 cylinder models. Separate accessories include oil switches, crankcase heaters, capacity control kits, head cooling fans and single phase electrics kits.

Size and Dimensions

Length：470 mm

Width：330 mm

Height：385 mm

Bolt Hole Size：295x279 mm

Connection Size (Liquid)：5/8"

Connection Size (Suction)：1 1/8"

Weight：82 kg

Model Number：DLSGP-40X-EWL

Product Range：K, L & S Standard Series

Technical Information

Compressor Horsepower：4 HP

Optional Capacity Control %：N/A

Compressor Displacement：22.5 m3/h

Number of Cylinders：2

Oil Charge：2 ltr

Oil Switch Required：No

Phase：3

Power Information:

Locked Rotor Current: (A)68.5 A

Maximum Operating Current:8.9 A

Power Supply:415V
