Name:	MBC 8100 061B810566 DANFOSS CONTROLES INDUSTRIALES MBC 8100 Thermostat M/6
Brand:	Danfoss
Model:	MBC8100
Part No.:	061B810566
County of origion:	Poland
G.W:	0.73kgs/pc
Max. sensor temperature [°C]:	250 °C
Product group:	Switches and thermostats
Quantity per packing format:	6 pc
Reset function:	Auto
Sensor pocket length min. [in]:	2 9/16 in
Sensor pocket length min. [mm]:	65 mm
Sensor size (Ø x L) [in]:	1/2 x 2 in
Sensor type:	Remote bulb

Product Description

MBC 8100 061B810566 DANFOSS CONTROLES INDUSTRIALES MBC 8100 Thermostat M/6

Thermostat, MBC 8100

061B810566

Temperature range [°C]: 60 - 150, Reset function: Auto, Contact function: SPDT, Sensor type: Remote bulb, Capillary tube length [mm]: 2000, Enclosure rating IP: IP65

Product details

Gross weight	0.73 Kilogram
Net weight	0.392 Kilogram

Volume	3.43 Liter
EAN	5702423190997

Ambient temperature range [°C] [max]	70 °C
Ambient temperature range [°C] [min]	-40 °C
Ambient temperature range [°F] [max]	158 °F
Ambient temperature range [°F] [min]	-40 °F
Approval	ABS BV CCC CCS CE DNV EAC GL KRS LLC CDC EURO-TYSK LR LVD NKK RINA RMRS RoHS RoHS China TYSK UKCA
Armoring	Yes
Cap. tube length fraction [in]	78 3/4 in
Capillary tube length [mm]	2000 mm
Charge type	Adsorption
China RoHS compliance	Yes
Connection for pocket or hose	M 18 x 1.5
Contact function	SPDT
Contact rating	AC15=0.5 A, 250 V DC13=12 W, 125 V
Differential (FS) [K]	6 K
Differential type	Fixed (max. value)
Electrical conn. Male/Female	Female
Electrical connection	DIN-plug
Electrical connection size	Pg 11
Electrical connection standard	EN 175301-803-A
Electrical spec. standard	EN 60947-5
Enclosure rating IP	IP65
Equipment	Armored cap. tube
EU RoHS compliance	Out of scope
In scope of WEEE and contain batteries	No

Max. sensor temperature [°C]	250 °C
Max. sensor temperature [°F]	482 °F
Packing format	Multi pack
Product accessories	Switches accessories
Product description	Thermostat
Product group	Switches and thermostats
Product Name Description	Thermostat
Quantity per packing format	6 pc
REACH Candidate List substances	Lead (CAS no. 7439-92-1)
Reset function	Auto
SCIP dossier no.	78250f8e-5849-44ad-ae3b-a65731351f9b
Sensor pocket length min. [in]	2 9/16 in
Sensor pocket length min. [mm]	65 mm
Sensor size (Ø x L) [in]	1/2 x 2 in
Sensor size (Ø x L) [mm]	13 x 50 mm
Sensor type	Remote bulb
Serviceable	No
Specification key	2631-1A02000
Temperature range [°C] [max]	150 °C
Temperature range [°C] [min]	60 °C
Temperature range [°F] [max]	302 °F
Temperature range [°F] [min]	140 °F
Type	MBC 8100
UK RoHS compliance	Out of scope
