Name:	Danfoss Change-over valve, DSV 2, 148F3011
Brand:	Danfoss
Model No.:	DSV 2
Part No.:	148F3011
Country of origin:	China
G.W:	11.6kgs/pc
Inlet connection type:	Weld flange
Outlet connection type:	G
Inlet connection size [mm]:	32
Inlet connection size [in]:	1 1/4 in
Outlet connection size [in]:	1 1/4 in

Danfoss Change-over valve, DSV 2, 148F3011

Characteristic	Value
EAN/UPC	5702428242486
Proposition 65	Cancer and Reproductive Harm

Characteristic	Value
Approval	CE, EAC, LLC CDC TYSK
Category	II
CE evaluated	Yes
China RoHS compliance	Yes with exemptions
China RoHS exemption clause	7.1, 7.2
Colour Paint	Reddish brown
Connection standard	EN 10220, ISO 228-1
Contains batteries	No
Cv value [gal/min]	34.800 gal/min
DG Indicator Profile	Not relevant for dangerous goods
Direction	Threeway
Equipment	Cap
EU RoHS compliance	Yes with exemptions
EU RoHS exemption clause	6(a), 6(b)
Fluid Group	1
Inlet connection size [in]	1 1/4 in
Inlet connection size [mm]	32.00 mm
Inlet connection type	Weld flange
Kv value [m³/h]	30.000 m³/h
Material Description	DSV2 FD32/FD32, DUAL STOPVALVE+KIT
Max. Working Pressure [bar]	40.0 bar
Max. Working Pressure [psig]	580 psig
Outlet connection comments	Thread flange
