Emerson Cold Storage Unit ZXD050BE-TFD-581

Emerson 5 HP Original Box-Type Integrated Condensing Unit

Brand: Copeland

Model Number: ZXD050BE-TFD-581

Country of Origin: China

Product Type: Refrigeration Unit

Place of Manufacture: Suzhou

Industry Certification: CCC

Application Field: Refrigeration/Freezing

Order Number: ZXD050BE-TFD-581

Alias: Refrigeration Unit

Type: Integrated Unit

Product Introduction

Emerson Climate Technologies has tailored the Lingdong Series scroll condensing units specifically for refrigeration applications, offering 2-9HP medium-temperature, digital medium-temperature, and low-temperature condensing units, as well as 12-20HP digital medium-temperature and digital low-temperature condensing units.

Energy Efficiency & High Performance

Significantly reduced power consumption is achieved through the use of Copeland Scroll™ compressor technology, variable-speed fan motors, large-capacity condensing coils, and enhanced control logic. Compared to hermetically sealed piston units, end users can achieve over 20% annual energy savings.

Reliability

  Combining the market-proven reliability of Copeland Scroll™ compressors with the enhanced CoreSense™ controller, unit reliability is substantially improved. Fault code alerts and reset functions provide information that accelerates and enhances system diagnostics. The CoreSense™ controller delivers protections against overcurrent, high discharge temperature, incorrect rotation, compressor frequent starts, high-pressure shutdown, and low-pressure shutdown. In the event of liquid slugging, the integrated electronic module also alerts operators to prevent major unit damage.
