Name:	DANFOSS - 060L113166 KP98 DUAL THERMOSTAT 060L113166
Brand:	Danfoss
Model:	KP98
Part No.:	060L113166
County of origion:	Poland
G.W:	0.686kgs/pc
Enclosure rating IP:	IP30
Capillary tube length [mm]:	1000
Sensor type:	Remote bulb
Contact function:	2 SPST(NC)
Reset function:	Manual Max
Product group:	Switches and thermostats
Quantity per packing format:	20 pcs
Sensor size (Ø x L) [in]:	3/8 x 4 1/2 in

DANFOSS - 060L113166 KP98 DUAL THERMOSTAT 060L113166

Product details

Gross weight	0.686 Kilogram
Net weight	0.62 Kilogram

Volume	2.003 Liter
EAN	5702428016490

Amb. Temp. Note	80 °C/176 °F for max 120 min
Ambient temperature range [°C] [max]	65 °C
Ambient temperature range [°C] [min]	-40 °C
Ambient temperature range [°F] [max]	150 °F
Ambient temperature range [°F] [min]	-40 °F
Approval	CCC CE CMIM EAC LLC CDC EURO-TYSK LVD PZH RINA RMRS RoHS China UKCA c UL us UL873, CS C22.2
Cap. tube length fraction [in]	39 3/8 in
Capillary tube length [mm]	1000 mm
Charge type	Adsorption
China RoHS compliance	Yes
Contact function	2 SPST(NC)
Contact rating	AC15=10 A, 400 V AC1=16 A, 400 V AC3=16 A, 400 V DC13=12 W, 220 V LR=112 A, 400 V
Diff. @ Max. range setting [K]	14 K
Diff. @ Max. range setting[°C]	14 °C
Diff. @ Min. range setting [K]	14 K
Diff. @ Min. range setting[°C]	14 °C
Differential type	Fixed
Electrical connection	Rubber cable gland
Electrical connection size	6-14 mm
Electrical spec. standard	EN 60947-5
EN 60947 electrical properties	Insulation: 400V Pollution degree: 3 Rated impulse voltage: 4 kV Short circuit prot, fuse: 16A
EN 60947 wiring properties	Flex, ferrules: 0.5-1.5 mm2 Flex, no ferrules: 0.7-2.5 mm2 Solid/stranded: 0.75-2.5 mm2
Enclosure rating IP	IP30
Enclosure rating Nema (~)	1
Equipment	Right side cap.tube 2 m
EU RoHS compliance	Yes
EU RoHS exemption clause	No
In scope of WEEE and contain batteries	No

Max. sensor temperature [°C]	150 °C
Max. sensor temperature [°F]	302 °F
Packing format	Multi pack
Product accessories	Switches accessories
Product description	Thermostat
Product group	Switches and thermostats
Product Name Description	Thermostat
Quantity per packing format	20 pc
REACH Candidate List substances	Lead (CAS no. 7439-92-1)
Reset function	Manual Max
Reset function, left side	Manual Max
Reset function, right side	Manual Max
SCIP dossier no.	be15a44e-80b1-41bd-9578-c8ff1cd7b9f3
Sensor size (Ø x L) [in]	3/8 x 4 1/2 in
Sensor size (Ø x L) [mm]	9.5 x 115 mm
Sensor type	Remote bulb
Serviceable	No
Temp. range left side [°C] [max]	120 °C
Temp. range left side [°C] [min]	60 °C
Temp. range left side [°F] [max]	250 °F
Temp. range left side [°F] [min]	140 °F
Temp. range right side [°C] [max]	180 °C
Temp. range right side [°C] [min]	100 °C
Temp. range right side [°F] [max]	350 °F
Temp. range right side [°F] [min]	210 °F
Type	KP98
UK RoHS compliance	Yes
UL approval file name	E31024
