Location:Index--->Product Center >> Danfoss Control >> 034G7074 DANFOSS REFRIGERATION M12 female angle connector cable 8m M/12

Name:	034G7074 DANFOSS REFRIGERATION M12 female angle connector cable 8m M/12
Brand:	Danfoss
Electrical connection:	M12
Part No.:	034G7074
Enclosure rating IP:	IP67
Operating temperature [°C] [max]:	80 °C
Operating temperature [°C] [min]:	-40 °C
Electrical conn. Male/Female:	Female
Cable length [m]:	8 m
Cable insulation material:	PVC
Cable feature:	Twisted pair
Product Name Description:	Cable
EU RoHS compliance:	Yes
Used for product comments:	Angleway connector

Product Description

Danfoss Electric valve accessories, Cable 034G7074

034G7074 DANFOSS REFRIGERATION M12 female angle connector cable 8m M/12

Used for product comments: Angleway connector, Type designation: Cable, Cable length [m]: 8.00, Used for product: ETS 100; KVS 3C; ETS 50; ETS 250; ETS 12C; ETS 400; KVS 2C; ETS 25; KVS 15; ETS 25B; ETS 12.5; ETS 50C; ETS 100C; ETS 25C; ETS 24C, Packing format: Multi pack, Quantity per packing format: 12

034G7073 2M

034G2330 2M

034G7074 8M

034G2200 8M

034G2323 8M

Product details

Gross weight	0.562 Kilogram
Net weight	0.514 Kilogram

Volume	1.764 Liter
EAN	5702428924825

Approval	CE EAC LLC CDC TYSK RoHS UKCA
Cable feature	Twisted pair
Cable insulation material	PVC
Cable length [ft]	26.2 ft
Cable length [m]	8 m
China RoHS compliance	Out of scope
Electrical conn. Male/Female	Female
Electrical connection	M12
Enclosure rating IP	IP67
EU RoHS compliance	Yes
EU RoHS exemption clause	No
In scope of WEEE and contain batteries	No
Operating temperature [°C] [max]	80 °C
Operating temperature [°C] [min]	-40 °C

Operating temperature [°F] [max]	176 °F
Operating temperature [°F] [min]	-40 °F
Packing format	Multi pack
Product group	Electric valve accessories
Product Name Description	Cable
Quantity per packing format	12 pc
REACH Candidate List substances	No
SCIP dossier no.	-
Type	Accessory
Type designation	Cable
UK RoHS compliance	Yes
Used for product	ETS 100 ETS 100C ETS 12.5 ETS 12C ETS 24C ETS 25 ETS 250 ETS 25B ETS 25C ETS 400 ETS 50 ETS 50C KVS 15 KVS 2C KVS 3C
Used for product comments	Angleway connector
