Dixell Thermostat Temperature Controller XR03CX-5N0C1

110V 230V Dixell Thermostat Controller XR Series Controller Digital Temperature

1.Model: XR03CX -5N0C1

2.Control mode:intelligent temperature control regulator

3.Measuring objects: cold cabinet, display cabinet, water chiller

4.Temperature range: - 50 to + 150 ℃

5.Temperature measurement error: 0.1 ℃

6.Installation type: embedded

7.Opening size: 71*29mm

8.Power supply: 110, 230Vac

9.Probe inputs

10.Thermostat: NTC

11.Digital inputs

12.Alarm, start defrost, AUX, door switch, pressure switch: Configurable

13.Relay outputs

14.Compressor: 8A, 20A optional

Other

Hot Key: Present

Buzzer: Optional (available only with 8A compr. Relay
